Providing optimum power, the ARB twin motor design delivers class-leading air flow for fast inflation purposes. Constructed of lightweight, high-strength engineering grade materials, it incorporates quality components for quiet operation and extended durability. The twin motors incorporate internal thermal protection against extreme temperature damage while a heavy duty in-line maxi fuse for each motor provides professional circuit protection. Available as either a portable kit with a 4L air tank, inflation accessories and a durable carry case or a vehicle mounted kit with associated wiring loom and mounting hardware.

The world's most highly regarded traction aid, an ARB Air Locker is a driver controlled locking differential originally designed to give serious 4 wheelers the traction needed to combat extreme off road terrain. When extra traction is required, the driver activates the Air Locker via a convenient dash mounted switch. Pneumatic pressure supplied by an on board air compressor engages ARB's patented locking mechanism within the Air Locker, thus preventing the wheels from turning independently. The Air Locker is deactivated by flicking a switch, returning the differential to normal.

Kit Includes

• RD100 Air locker
• RD117 Air locker
• CKMA12 High performance air compressor (compact, operates up to 2 air lockers)
• 171302 Pump up kit
• ARB605 Inflator with gauge
• Air locker key chain
• Air locker hat

Features

• Easy maintenance
• Air activated selectable locker
• Simple push button operation
• Thoroughly tested and proven
• Converts from open differential to fully locked or spool
• Vastly improved traction means less reliance on momentum reducing the likelihood of vehicle damage
• Easy convenient operation without leaving the comfort and safety of the drivers seat
• Ultra durable and extremely strong only the highest quality materials used in construction
• Patented gear technology and 2-piece design ensures optimal locking strength

Specifications

• Drivetrain: 4x4
• Position: Front and Rear
• Gear Ratio: All JK gears
• Axle Splines: 27/30
• Ring Gear Bolts: 10
• Ring Gear Bolts Size: 3/8"
• Weight: 80 lb

• Fits Jeep Rubicon JK
• 4.11 ratio
• Includes front and rear ring & pinion sets and master overhaul kits

The Axle Assurance Kit is designed to strengthen the D30/D44 front axle found in the front of the Jeep JK before it is bent/broken from the abuses of large tires and off road use. The Inner Axle Sleeves provide a 59% increase in strength over the stock axle tubes by being machined to fit snugly inside, increasing the overall tube thickness. The Inner C Gussets are laser cut and CNC bent in a heavy duty 3-sided construction to reinforce the Inner C's in the two planes prone to bending. The Lower Control Arm Skids are also laser cut and CNC bent to provide a very rigid bracket protecting the lower control arms and axle mounts. The Inner Axle Seals are the finishing touch to assist in putting everything back together. We also recommend the installation of our HD Ball Joints at this time to further extend the life of the axle.

Jeep JK Axle Assurance Kit Includes:

• (1) 8012-02 Jeep JK D30/44 Inner C Gusset Kit
• (1) 8012-09 Jeep JK D30 Inner Axle Sleeve Kit
• (1) 8012-03 Jeep JK Lower Control Arm Skid Plate
• (1) 8009-13 Jeep JK D30/44 Inner Axle Seal Kit

Notes:

• Inner Axle Sleeves are not compatible with Jeep JK Rubicon Recon models due to thicker axle tube housings.
• Inner C Gussets may need to be modified to fit Jeep JK Rubicon Recon models due to upgraded axle end forgings.

The TeraFlex JK: HD Forged Drag Link Kit & HD Chromoly Tie Rod Kit withstands extreme conditions and abuse that typically causes factory steering components to bend and fail on lifted JK Wrangler/Unlimited models.

HD Forged Drag Link Kit – (# 1853920)

• Bolts directly to new High Steer Knuckle (not included)

• 50% stiffer than factory drag link to help eliminate front end shimmy and other alignment issues

• 1.25" O.D. fully forged drag link eliminates excess movement during hard steering maneuvers

• Utilizes oversized DOM factory-style adjusting collar and pinch clamp for simple adjustments

• Tie rod joint incorporates same features found in TeraFlex Ball Joints, including 4140 chromoly ball/stud and 1045 carbon steel housing

• Adjustable joint preload tension to ensures proper long-term durability

• Joint is pressed into rod end housing and secured w/ snap ring

• Provides clearance for factory 17" wheels HD Chromoly Tie Rod Kit (# 1853910)

• HD 1-5/8" O.D. 4140 heat treated chromoly steel

• More than 200% stronger than factory tie rod

• Forged tie rod housing designed specifically for JK Wrangler/Unlimited

• Tie rod end joint incorporates same features found in TeraFlex ball joints, including 4140 chromoly ball/stud and 1045 carbon steel housing

• Features adjustable rod end preload tension to ensure long-term durability

• The joint is pressed into the rod end housing and secured w/ a snap ring

• Tie rod end joint rotation is limited to 14 degrees of movement to minimize tie rod roll

• Provides clearance for factory 17" wheels

• Steering Stabilizer Relocation Mount Bracket Kit – HD Tie Rod (# 1123160) Steering Stabilizer Relocation Mount Bracket Kit – HD Tie Rod (# 1123160)

• Fits heavy-duty 1-5/8" tie rod

• 6061-T6 aluminum clamp and forged 10.9 grade stud

• Moves steering stabilizer up nearly 2.5" to help reduce damage to the stabilizer shaft or body

• Repositions stabilizer to reduce tie rod roll" associated w/ stabilizer misalignment
